SZ-L Cantilever Beam Sensor

High precision, high reliability and good interchangeability, suitable for hoisting machinery such as mobile cranes, portal cranes and gantry cranes.
Accuracy class: ≤±0.02%
Input impedance: 380±150 Ω
Output impedance: 350±20 Ω
Insulation resistance: ≥5000 MΩ
Excitation voltage: ≤15V
Safe overload: 150%F.S.
Temperature range: -30°C~+70°C
Protection level: IP66, IP67
