SZ-X Shaft Pin Sensor

Used for rigging shackles, movable/fixed pulley riggings, connecting forks and lifting rings, replacing the original shaft of hoisting equipment.
High precision, high reliability and easy installation.
Accuracy class: ≤±0.02/0.05%
Sensitivity: 1~1.5±0.005mV/V
Input impedance: 770±20Ω
Output impedance: 700±2Ω
Insulation resistance: >5000MΩ
Excitation voltage: ≤15V
Safe overload: 150%F.S.
Temperature range: -30°C~+70°C
Protection level: IP66, IP67
